- U.2600.025.TO.C
Product Details
| Configuration | |
| Charging Pressure (bar) (15 to 150) | |
| Mount Option | |
| Series | U |
| Model | 2600 |
| Stroke Length Order Code (mm) | 025 |
| S (mm) | 25.0 |
| C (mm) (mm) | 70.0 |
| Overall Length (mm) | 95.0 |
| Max On-Contact Force (lb) | 5362 |
| Max On-Contact Force (daN) | 2386 |
| Can Diameter (mm) | 75.0 |
| Documentation | |
| Catalog/Bulletin | u_catalog.pdf |
